Automatic electrical 11-33KV CIRCUIT BREAKER recloser kema

FOB Reference Price:Get Latest Price
$6,000.00 - $16,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 10 11 - 50 >50
Est. Time(days) 30 45 Negotiable
Customized logo (Min. Order: 2 Sets)
Customized packaging (Min. Order: 2 Sets)


Graphic customization (Min. Order: 2 Sets) Less
Report Suspicious Activity
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
Model Number:
Poles Number:
Product name:
Automatic electrical 11-33KV CIRCUIT BREAKER recloser kema
Rated current:
Rated voltage:
Rated short circuit breaking current:
Rated frequency:
50/60 Hz
Mechanical Life:
20000 Times
IEC Standard
Opening speed:
1.5±0.2 m/s
Supply Ability
Supply Ability:
500 Set/Sets per Month Automatic electrical 11-33KV CIRCUIT BREAKER recloser kema
Packaging & Delivery
Packaging Details
Wood case per set or according to client's requirements
Automatic electrical 11-33KV CIRCUIT BREAKER recloser kema
Any port in China
Lead Time :
Quantity(Sets) 1 - 10 11 - 50 >50
Est. Time(days) 30 45 To be negotiated

Automatic electrical 11-33KV CIRCUIT BREAKER recloser kema




Vacuum CB

ZW32-12C outdoor high-pressure vacuum auto-recloser is used for AC 50Hz, 12kV three-phase power distribution network system. The recloser is capable of automatically breaking and reclosing operations in the AC line according to the predetermined billing and coincidence sequence. The high-voltage switchgear with its own control protection function after automatic reset or latching can be used together with the segmenter to realize distribution automation without additional control system. This system can quickly segment and isolate faults, and will have power failure range. It is the ideal equipment for urban rural network reform, and the recloser can be equipped with isolation switches according to user requirements.
This circuit breaker needs to be equipped with a voltage transformer.




 Feature advantages

 1, using vacuum arcing chamber, with SF6 gas as auxiliary insulating medium, with spring operating mechanism, realizes the devoid of oil;

 2, open circuit performance is good, long life, is 20 times;

 3, can open circuit current is 630 a single capacitor group without renewed;

 4, mechanical life is long, can reach 20000 times, reliable action, frequent operation, low noise;

 5, has lost the breaking capacity, can be used for contact circuit breaker;

 6, according to user requirements, can not with CT or most with 12 CT;

 7, products, beautiful shape, anti-corrosion ability is strong, simple structure, no maintenance cycle is long and easy in maintenance.




Technical data

No.       ItemUnitParameters
1Rated voltagekV12
2Rated currentA630/800/1250/1500
3Rated frequencyHz50/60
4Lightning impulse withstand current (peak)kV50
5Rated short-circuit breaking currentkA12.5/16/20
6Rated short-circuit current (peak)kA31.5/40/50
7Rated peak withstand currentKa31.5/40/50
84S short-time withstand currenkA31.5/40/50
9Rated operating cycle Sub-0.3s-Hop sub-180s-Hop sub-
10Rated short-circuit current breaking timeTimes20
11Mechanical lifeTimes20000
12Secondary circuit 1min power frequency withstand voltageKV2
13Opening speedm/s1.5±0.2
14Closing speedm/s0.7±0.2
15Motor Voltagem/sAC/DC 110/220
17Standard IEC
Factory equipment

Our partner is a large-scale manufacturer of circuit breaker electric equipment. During first Five-Year-Plan it has become an important base for developing and manufacturing in China after many years of development.





The products involving power networks have been put into operation everywhere in China and also exported to many foreign countries and regions. The Company has decades of experience of manufacture. The products are stable in performance, reliable in quality, advanced in technology. The performances of products reach  advanced international standars, as demostrating by the obtaining of International Certificates.



Packaging & Shipping

Our packing experts will work with you and your product’s specifications, and provide solutions for packaging options to ensure safe transport and delivery.

Packaging:Wooden case, container or according to client's requirements

Shipping:Land transportation and Ocean transportation


The standard procedure for making wooden case is as follows:

♦ Receipt of information required for the type of goods to be wood barrel customers.

♦ Measure and create original designs for customers.

♦ Select the type of wood suitable for the requirements of the goods.

♦ Determine the delivery time.

♦ Check the wood barrel technique.

♦ Handover confirmation.






Our products have been shipped all around the world, with an extensive logistic network, we provide the best transportation option for our clients.






Quality and excellence in services


A good brand must be supported by good products, but good products must be supported by an excellent service.

We provide customers with product information support from product purchasing information to other business support services. Technical support is available for a complete series of products, including product consulting, type selection & replacement, simple application & installation, and FAQ.



We have always been focussing on our users, not only ensuring the product quality, but also building an after-sale service.On the basis of training a team of high-quality service personnel, we applied a set of complete quality traceability system on the after-sale products by keeping a close contact with our customers, providing them with standardized and professional service, helping them removing the trouble back at home.


Your satisfaction is our untiring PURSUIT!



Q:How long have you been working in the electric industry field?
A:We have been working in the electric industry for nearly 20 years.

 Q: How long is your delivery time?
A: Generally it is 20 days for stock. if the goods are not in stock is around 30 days , also it is according to quantity.

Q: To which markets have you already sell?

A: We have already shipped to Europe, Middle East, South America, Asia, Afria etc.

 Q:Why choice Daelim?

A:After comparing quality,delivery and price you will find out the answer.



International standards


Our products meet the requirements of national and international standards. This has been confirmed by comprehensive type tests according to the latest IEC and ANSI standards.
