10kv 11kv rated voltage casting insulation post type current transformer price

FOB Reference Price:Get Latest Price
$299.00 - $399.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China
Brand Name:
Daelim
Model Number:
11kv current transformer
Usage:
Electronic
Phase:
single or three
Coil Structure:
Toroidal
Coil Number:
1-8
key words:
10kv 11kv casting insulation post type current transformer price
rated frequency:
50/60Hz
usage:
electric energy, voltage controlling and relay protection applications
Ambient temperature:
-5 ~40 degrees
relative humidity:
85% or below at 20 degrees
Altitude:
<1000m
accuracy class:
0.2 or 0.5
Rated primary current (A):
5-6000A
Certification:
ISO
Standard:
IEC60076
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden case or according to customer's request
Port
Tianjin/Shanghai/Guangzhou etc
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 To be negotiated

10kv 11kv rated voltage casting insulation post type current transformer price

Product Description

The current transformer is full enclosed and post type. It is small and light. There are four mounting hole of 12 in bottom, but the primary output should be fixed for the reliable connections. There are one or two ratios.



1. Rated insulated level: 12/42/75kV;

2. Rated secondary current: 5A, 1A;

3. Rated primary current, accuracy classes combination, rated output, rated dynamic and thermal current see form;

4. The conditions of the partial discharge test according to GB1208-2006 current transformer will be fulfilled without exception.

5. Antipollution class: class||.



Rated primary current(A)

Accuracy classes

Rated output(VA)

Rated short-time thermo-current(KA virtual value)

Rated short-time

thermo-current

(kA virtual value)

Note

20~30

0.5S/10P10

0.2S/10P10

0.2/10P10

10P10/10P10

10

15

10

15

1.6/2

4

Double

ratio

30~40

3.15/2

8

40

50~75

6.3/2

16

75~100

100~150

8/2

20

150~200

200~300

12.5/4

31.5

300~400

20/4

50

400~600

600~800

15

20

25/4

63

800~1000

31.5/4

80
