DW15 Series Intelligent AC380V 45ka 800amp air circuit breaker

FOB Reference Price:Get Latest Price
US $2,250-2,999 / Set | 1 Set/Sets DW15 Seires Intelligent AC380V 45ka 800amp air circuit breaker (Min. Order)
Supply Ability:
1000 Set/Sets per Month DW15 Seires Intelligent AC380V 45ka 800amp air circuit breaker
Port:
Tianjin/Shanghai etc.
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
Daelim
Model Number:
DW15
Usage:
Power
Phase:
Three
Coil Structure:
Other
Coil Number:
Other
Product name:
DW15 Series Intelligent AC380V 45ka 800amp air circuit breaker
Rated Current:
800 (A)
Rated Capacity:
40 (kA)
Frequency:
50Hz/60Hz
Type:
AC380V
Mechanical life:
5000 (times)
Operation frequence:
30 (times/h)
Certification:
ISO, UL, CE
Standard:
IEC
Packaging & Delivery
Packaging Details
International Standard Wooden Case. One unit, one case for AC380V 45ka 800amp air circuit breaker
Delivery Time
15-25 days after confirming the drawing

DW15 Series Intelligent AC380V 45ka 800amp air circuit breaker

PRODUCT DESCRIPTION
DW15 series intellegent air circuit breakers (hereinafter called circiut breaker) are applied for the network circuit of AC 50Hz, rated voltage 1140V, and rated current up to 4000A. Mainly used to prevent the circuit. Frame current below 630A can also be used in AC 50Hz 380 electric network to protect the motor from overload, undervoltage and short circuit.
The breaker can be used to switch the circuit and start the motor infrequently. Frame currnet below 630A can be used to switch the circuit and start the motor infrequently.
The products cofirm with IEC60947-2.

Main technical parameters for DW15 Intellegent Air Circuit Breakers
Frame class current Inm(A)630160025004000
Rated current In(A)200, 400630, 8001600, 20002500, 3200
6301000, 1250, 160025004000
Rated
breaking
capacity(kA)
AC380V
AC660V
Short circuit
breaking
(Note 1)
AC380V
AC660V
30456080
20---
Mechnical life (Note 2) (times)10000500050004000
Electrical life (1In, 1Ue) (times)1000500500500
Operation frequence (times/h)60302010
Arcing distance (mm)280350350400
Trip typeThermal
electromagnetic
Thermal
electromagnetic
Thermal
electromagnetic
Thermal
electromagnetic
ElectromagneticElectromagneticElectromagneticElectromagnetic
For other group and the corresponding technical parameters of connection for non-optimal parameters, feel free just contact me!



MANUFACTURE

Daelim is rich in international power projects. With the excellent  team, Daelim can offer the best solution and top valued equipments according to the project.







PACKAGING & SHIPPING

 The standard procedure for making wooden case is as follows:

♦ Receipt of information required for the type of goods to be wood barrel customers.

♦ Measure and create original designs for customers.

♦ Select the type of wood suitable for the requirements of the goods.

♦ Determine the delivery time.

♦ Check the wood barrel technique.

♦ Handover confirmation of work efficiency.





OUR SERVICE

♦ Provided efficient and fast services to clients.

♦ Provide through support and problem resolution for customers.

♦ Maintain composure and patience in face of difficult customer situations.

♦ Build and maintain successful relationships with our consumers.

♦ Train employees and explain how to use equipments clearly and efficiently.





OUR CUSTOMERS





Our turnover in the past few months





CERTIFICATIONS





OUR COMPANY

         Beijing Daelim Green EP Tech Co., Ltd. is mainly engaged in the import & export of electric products and equipment. Our business team has more than 15 years foreign business experience, and also has a unique understanding of electrical products and overseas markets. We have established and extended business relationships with customers and partners in Southeast Asia, the Middle East, Europe, Africa, North America and South America.

        The company has invited experts and engineering technicians from large and mediun-sized transformer factories as its managerial and technical personnel.All production& manufacture procedures are under strict control,and all process tests&ex-work tests are computer-operated.The production material,technology and equipment for dry type transformers are imported from DUPONT,which make it qualified for manufacturing different transformers.

http://www.daelim-electric.com







CONTACT INFORMATION

Please offer the following information before inquiring or ordering to begin our cooperation
(1) Rated capacity,  (2) Voltage, (3) Range of tapping, (4) Vector group, (5) Short circuit impedance, (6) No.load loss, (7) On.load loss, (8) No.load current, (9) Rated frequency, (10) Cooling method, (11) Altitude,  (12) Working environment and other special requirements.

If you need more information about our products, feel free contact!!!
