High quality manufacture 24kv polymer suspension Insulator

FOB Reference Price:Get Latest Price
US $15-150 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
daelim
Model Number:
6051
Type:
Insulator
Material:
Composite Polymer
Application:
High Voltage
Rated Voltage:
24kv, 24kv
Tensile Strength:
10.4Mpa
keywords:
polymer suspension insulator
Feature:
High Temperature Resistance
Certification:
ISO9001
Brand name:
Daelim
Standard:
IEC 61109
Product:
insulator
Usage:
Insulation Protection
Product name:
High quality manufacture 24kv polymer suspension Insulator
Name:
suspension Insulator
SupplyAbility
SupplyAbility:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
By carton or plywood case.
Based on clients' requirement.
Port
Shanghai
Lead Time :
Within 45 days after received your payment

High quality manufacture 24kv polymer suspension Insulator



Product Description





Description of polymer suspension insulator:

Composite suspension insulator is composed of fiberglass epoxy resin lead-out rod, silicon rubber housing and hardware, and is manufactured with once-molding technique and special colloid installation and compression technique. The insulator is featured by excellent electrical characteristics, small volume and less weight.

 Features of polymer suspension insulator:

1. High mechanical strength.

2. Good resistance to flashover.

3. Small volume and light weight.

4. Good sealing performance.





Technical data:

Model Rated Voltage(kv) Section Length (H)Dry Acring Dustance (mm)Housing Dia (d) (mm) Shed Diameter D1/D2Shed Distance (a)(mm)wet Power Frequency Withstand Voltage (KV)Reference  Weight (kg)
CS70CT-145/50524395241237535≥501.16
CS70CT-170/60424450292237535≥551.23
CS70EE-170/60424466292237535≥551.28
CS70CT-200/86724485341239835≥801.43
CS180S20B20-550/369024135011303485.1680≥2307.2





Product structure of polymer suspension insulator :





Packaging & Shipping

Packing And Shipping Shows





Application

Our products include: Power transformer, Circuit breaker, Disconnector switch,.Current transformer & Potential transformer which are wildly applied to power station, transformer substaion,  power distribution station.



Certifications



Company Information

Beijing Daelim Green EP Tech Co., Ltd. is mainly engaged in the import & export of electric products and equipment. Our business team has more than 15 years' foreign business experience, and also has a unique understanding of electrical products and overseas markets. We have established and extended business relationships with customers and partners in Southeast Asia, the Middle East, Europe, Africa, North America and South America.


The main products and equipment we are dealing with: power transformer, current transformer, potential transformer, vacuum & SF6 circuit breaker, load break switch, disconnector, switchgear panel, power plant, transmission line equipment.


We provide competitive prices, high quality products, timely shipment and efficient services to develop our cooperation with all of our customers. We are trading in accordance with international traditions and practices. We would like to extend business with our customers and partners on the basis of cooperation and mutual benefit..
