High Efficiency Hydroelectric Generator For Small / Medium Plant

FOB Reference Price:Get Latest Price
US $1,000-10,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
10000 Piece/Pieces per Month
Port:
China port
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China (Mainland)
Brand Name:
Daelim
Model Number:
customization
Type:
Other
type:
Hydroelectric Generator
Packaging & Delivery
Packaging Details
Package can be either suitable for sea or air shipment.
Delivery Time
The delivery date is accoding to customer's requirement.

High Efficiency Hydroelectric Generator For Small / Medium Plant



Product Specifications

Type

High Power Pelton Turbine

Water Head



From 75m to 700m

Installed Capacity

From 55KW to 6300KW

Runner Material

Stainless Steel. Cast

Generator Type

Synchro Generator

Auxiliary Equipment

Governor, Inlet Valve, Unit Side Panel, Excitation System



We have more than 100 kinds of models, here are parts of them:



Model

Water head(m)

Flow(m³/s)

 Revolving speed (r/min)

Generator model

Governor

Inlet valve

CJ22-W-45/1*4.5

110

0.0709

932

SFW55-6/493

TT-35

Dg250

130

0.0771

1013

SFW75-6/493

160

0.0856

1124

SFW100-6/560

HLD54-WJ-50

77

0.57

1088

SFW320-6/740

T-150A

Dg500

89.7

0.61

1174

SFW400-6/850

104

0.66

1264

SFW500-6/850

XJA-W-63/1*16

100

0.855

635

SFW630-10/1180

YTT-75

Dg500

120

0.937

696

SFW800-8/1180

140

1.012

751

SFW1000-8/1180





Note:

Any other sizes are available according to customers' special requests. If you are interested in our products, please send us some key parameters (such as net head, water flow, installed capactiy, unit number, frequency, voltage) in inquiry and contact us.



Products Introduction:

Pelton water turbine is the best choice to make use of high head and small flow water resourses.Our pelton turbine runner diameter is 0.4-1.2m,which adapt to the water head of 50-500m,and the capacity is 24-3200KW.Francis Water turbine generator set is used to exploit high head, medium flow water recourses. Our francis water turbine runner diameter is 0.25-1.5m, which adapt to the water head of 10-339m, and the installed capacity is 75-6300KW. The inclined-jet turbinemainly used in high waterhead and low flow rate power station . The inclined-jet’s runner diameter is 0.32~0.8 meter , it can be suitable for water heads 60~150 meter, and its capacity is75~1600 KW. The Kaplan turbine mainly used in medium or high water head and high flow rate water resources . The Kaplan turbine which we produced with its runner diameter 0.4~2.00 meter, can be suitable for water heads 3~14.6 meter , and its capacity is 55~2500 KW.



Superiority of Our Products:

1.We can provide the complete equipment, including: water turbine, generators, inlet valve, governor, computer control panel, and other ancillary equipment.



2.Our production ability and quality of Francis Turbine runner own quite Reputation prominent in China among all the small and medium sized enterprises.
